McConnell-Marc 450

Last Updated: June 2024

Overview

The McConnell-Marc model 450 is categorized as a compact utility tractor with a reliable 4-wheel drive system, suitable for a variety of tasks around a small farm or large garden. Its chassis incorporates a 4x4 MFWD 4WD configuration, emphasizing its capability in various terrains and conditions. The tractor is powered by a robust 50 horsepower engine made by Yangzhou, designated as model 495T. This engine is a 4-cylinder liquid-cooled diesel engine with a displacement of 198.9 cubic inches and operates at a rated speed of 2000 RPM. This workhorse is operated through a simple gear transmission with 8 forward and 2 reverse gears. For ease of operation, the tractor comes with power steering. The dimensions of the tractor reveal a wheelbase of 82 inches and an overall length of 141.5 inches, which combined with an operating weight of 6100 lbs, ensures stability during use. The physical stature stands tall at 92 inches. This tractor utilizes agricultural tires with sizes 9.50-24 for the front and 14.9-28 for the rear, aiding in superior traction and field performance. While specific details on hydraulic systems, PTO speeds, and starter types are not provided, the model 450 maintains a strong presence among compact utility tractors for those seeking a blend of power and size.
Show more...

Key Specifications

Category: Utility

Power Output: 50

Transmission: Gear

Drive Type: 4WD

Operating Weight: 6100

Fuel Type: Diesel

McConnell-Marc 450 vs. Similar Tractors

Power Output
Average
Greater than 49% of similar tractors.
Operating Weight
Average
Greater than 48% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yangzhou
Model
495T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
198.9
Bore (in)
3.74
Stroke (in)
4.53
Rated RPM
2000
Power Output (hp)
50

Transmission

Type
Gear
Forward Gears
8
Reverse Gears
2
Total Gears
10

Dimensions

Length (in)
141.5
Width (in)
-
Height (in)
92
Operating Weight (lb)
6100

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
24
Front Tire Width (in)
9.5
Rear Tire Diameter (in)
28
Rear Tire Width (in)
14.9
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
12 volts
Brake Type
-
Hydraulic System Type
-
