Massey Ferguson 8735

Last Updated: July 2024

Overview

The Massey Ferguson 8735 specifications have been updated based on independent test results from the Nebraska Tractor Test Laboratory (January to April, 2015). Key changes include: clarification of transmission details with speed ranges, engine induction type with two turbochargers and DEF technology, engine displacement of 513 ci, operating weight of 24,670 lbs, detailed fuel consumption data, DEF fluid specifications, power take-off performance, hydraulic system flow discrepancy, and additional chassis/mechanical details such as tread widths, axle lubricants, and operator station type. Comprehensive performance data from the test results has been incorporated into the Additional Features field.

Key Specifications

Power Output: 287 (Maximum)

Transmission: Continuously variable transmission (CVT) with two mechanical ranges

Operating Weight: 24670

Fuel Type: Diesel

Lift Capacity: 10970.3 lbs at 24 inches

Image Gallery

Massey Ferguson 8735 Tractor

Technical Specifications

Engine

Manufacturer: AGCO POWER
Model: AGCO Power 8.4L
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: 24-valve
Fuel Type: Diesel
Induction Type: Two turbochargers, air to air intercooler and DEF (diesel exhaust fluid) technology
Cylinders: 6
Displacement (ci): 513
Bore (in): 4.37
Stroke (in): 5.71
Rated RPM: 2100
Power Output (hp): 287 (Maximum)

Transmission

Type: Continuously variable transmission (CVT) with two mechanical ranges
Forward Gears: Forward Low range: 0-20 mph (0-32 km/h), High range: 0-25 mph (0-40 km/h)
Reverse Gears: Reverse Low range: 0-12 mph (0-20 km/h), High range: 0-18 mph (0-30 km/h)
Total Gears: -

Dimensions

Length (in): 218.6
Width (in): -
Height (in): 141 (cab height)
Operating Weight (lb): 24670

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: -
Steering Type: Hydrostatic power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: -
Manufacture - End Year: -
Hitch Type: III/IVN
Hitch Category: -
Hitch Position: Rear
Hitch Capacity (lb): 10970.3 lbs at 24 inches
Operator Station Type: -
Starter Type: Electric
Brake Type: -
Hydraulic System Type: Closed center load sensing (CCLS)

Test Results

Nebraska Tractor Test Laboratory - Test Date: January to April, 2015

Maximum Power and Fuel Consumption

Maximum Power: 287.0 HP (214.0 kW) at 2100 rpm
Fuel Consumption at Maximum Power: 17.01 Gal/hr (64.4 l/h) with a fuel efficiency of 0.378 lb/hp.hr (0.230 kg/kW.h)
DEF Consumption: 0.82 Gal/hr (3.10 l/h)

Drawbar Performance

Maximum Drawbar Power: 234.4 HP (174.8 kW) with a drawbar pull of 18185 lbs (80.9 kN) and a speed of 4.83 mph (7.78 km/h)
Fuel Consumption at Maximum Drawbar Power: 0.502 lb/hp.hr (0.306 kg/kW.h) with a fuel efficiency of 13.76 Hp.hr/gal (2.71 kW.h/l)

Torque and Engine Performance

Maximum Torque: 1010 lb.-ft. (1370 Nm) at 1507 rpm
Torque Rise: 41.3% with a power increase at 1948 rpm of 9.5%

Hydraulic Performance

Maximum Force Exerted: 22460 lbs (99.9 kN) at hitch points (QA ends)
Pump Delivery Rate: 53.1 GPM (201.1 l/min) at minimum pressure and rated engine speed
Hydraulic Power: 67.3 HP (50.2 kW) at delivery pressure of 2435 psi (168 bar)

Overall Efficiency

Fuel Efficiency at Standard PTO Speed (1000 rpm): 18.23 Hp.hr/gal (3.59 kW.h/l)
Fuel Consumption: 17.01 Gal/hr (64.4 l/h) at 1970 rpm

Nebraska Tractor Test Lab.(2015).Nebraska Summary: S992 Massey Ferguson 8735 Diesel. Lincoln, NE:Nebraska Tractor Test Laboratory. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/3304
