Massey Ferguson 698T

Last Updated: September 2024

Overview

The Massey Ferguson 698T is a row crop tractor built for farm work. It has two big wheels in the back and two smaller wheels in the front, which is called a 2WD setup. This tractor uses a special steering system that makes it easy to turn, even when the engine isn't running.

The 698T has a Perkins A4.236 engine with four cylinders. This engine is turbocharged, which means it can make more power. It runs on diesel fuel and is cooled by liquid. The engine size is below average at 236 cubic inches. It spins at 2200 rpm when working hard, which is above average speed for tractors. The tractor has 12 gears for going forward and 4 for going backward, giving the driver lots of choices for different jobs. It starts up easily with an electric starter, just like a car.
Show more...

Key Specifications

Category: Row Crop

Transmission: Multi-Power

Drive Type: 2WD

Fuel Type: Diesel

Massey Ferguson 698T vs. Similar Tractors

Engine Displacement

The Engine Displacement for the Massey Ferguson 698T is Below Average. It is greater than 13% of similar Row Crop tractors in our database.

Engine displacement distribution of Row Crop tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Massey Ferguson 698T is Average. It is greater than 57% of similar Row Crop tractors in our database.

Engine rated RPM distribution of Row Crop tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Perkins
Model
A4.236
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement
236 ci (3.9 L)
Bore
3.88 in (98.4 mm)
Stroke
5.00 in (127.0 mm)
Rated RPM
2200

Transmission

Type
Multi-Power
Forward Gears
12
Reverse Gears
4

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
