Massey Ferguson 670

Last Updated: June 2024

Overview

The Massey Ferguson 670 is a utility tractor which was manufactured from 1983 to 1986. Boasting a robust chassis with a 4x2 2WD configuration, this model comes equipped with a 12-speed manual transmission and power steering, enhancing maneuverability and control. A prominent feature of the 670 is its Perkins AD4.236 diesel engine, which features a 4-cylinder, liquid-cooled design with a displacement of 236 cubic inches, running at a rated 2000 RPM and delivering a gross power of 62 horsepower. Its operating weight of 8,720 pounds underscores a solid, durable build suitable for a range of utility tasks. Despite comfortably sitting in the utility tractor category its specific tire dimensions were not documented, but it did typically come with agricultural tires. Its physical dimensions stand at about 154 inches in length and 81 inches in width. Additional details regarding the tractor's height, hydraulic lift capacity, PTO, and braking systems remain undocumented. The 670's operational features such as direct injection for fuel delivery, a dry disc clutch, and an electric starter, cater to efficiency and reliability in agricultural settings.
Show more...

Key Specifications

Category: Utility

Power Output: 62

Transmission: Manual

Drive Type: 2WD

Operating Weight: 8,720

Fuel Type: Diesel

Massey Ferguson 670 vs. Similar Tractors

Power Output
Average
Greater than 59% of similar tractors.
Operating Weight
Poor
Greater than 4% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
AD4.236
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
4
Displacement (ci)
236
Bore (in)
3.875
Stroke (in)
5
Rated RPM
2000
Power Output (hp)
62

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
154
Width (in)
81
Height (in)
-
Operating Weight (lb)
8,720

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
1986
Hitch Type
-
Hitch Category
II
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
