Massey Ferguson 6615 DYNA 4

Last Updated: June 2024

Overview

The Massey Ferguson 6615 DYNA 4 is a utility tractor with a turbo intercooled engine and a semi-powershift transmission. It is designed to deliver a balance of power and maneuverability, suited for a variety of agricultural tasks. The tractor is powered by a 4-cylinder AGCO POWER engine with a displacement of 299.1 cubic inches, generating 145 horsepower. It includes a high-capacity hydraulic system indicated by a pump flow capacity of 15.4 gallons per minute and an operating pressure of 2900.8 psi, accompanied by four remote control valves. Moreover, it boasts a robust 3-point hitch lift capacity of 15,652.9 pounds. The tractor's frame allows for an operating weight of 11,905 pounds and accommodates sizable tires with specifications of 14.9 R 28 for front tires and 18.4 R 38 for the rear, enabling a max speed of 24.9 mph. The dimensions contain an overall length of 185.1 inches and a notable height of approximately 10 feet with ROPS/FOPS.
Show more...

Key Specifications

Category: Utility

Power Output: 145

Transmission: Semi-powershift

Operating Weight: 11905

Lift Capacity: 15652.9

Massey Ferguson 6615 DYNA 4 vs. Similar Tractors

Power Output
Excellent
Greater than 90% of similar tractors.
Hitch Capacity
Above Average
Greater than 90% of similar tractors.
Operating Weight
Average
Greater than 65% of similar tractors.

Technical Specifications

Engine

Manufacturer
AGCO POWER
Model
2nd Generation SCR
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
Turbo Intercooled
Cylinders
4
Displacement (ci)
299.1
Bore (in)
-
Stroke (in)
-
Rated RPM
-
Power Output (hp)
145

Transmission

Type
Semi-powershift
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
185.1
Width (in)
-
Height (in)
120 (approximation based on the height of the ROPS/FOPS)
Operating Weight (lb)
11905

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
15652.9
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
