Massey Ferguson 5460SA

Last Updated: June 2024

Overview

The Massey Ferguson 5460SA is a tractor that was manufactured between 2004 and 2010 as part of the 5400 Series. It is equipped with a Perkins 1104 engine that provides 105 hp, is turbocharged, and operates at 2200 rpm. With a liquid-cooled system and a displacement of 268.5 cubic inches, the 4-cylinder diesel engine offers robust performance for various farming operations. The tractor features a 2WD (two-wheel drive) chassis and hydrostatic power steering to enhance maneuverability. The Speedshift transmission includes 16 forward and reverse gears, adapting to various tasks with ease. Its open center hydraulic system is complemented by an alternator supplying 120 amperes and a pump flow capacity of 26 gallons per minute. The tractor operates with a weight of 7838 lbs and has dimensions with a width of 79.1 inches and a height of 97 inches. A Category II hitch system provides a lift capacity of 6600 lbs, and the fuel capacity of 37 gallons ensures extended operation times. Overall, the Massey Ferguson 5460SA is designed for effective performance and reliability across various agricultural demands.
Show more...

Key Specifications

Power Output: 105

Transmission: Speedshift

Drive Type: 2WD

Operating Weight: 7838 (2WD)

Fuel Type: Diesel

Lift Capacity: 6600 lbs

Technical Specifications

Engine

Manufacturer
Perkins
Model
1104
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
268.5
Bore (in)
3.937
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
105

Transmission

Type
Speedshift
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
-
Width (in)
79.1
Height (in)
97
Operating Weight (lb)
7838 (2WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
2010
Hitch Type
Category II
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
6600 lbs
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
Open center
