Massey Ferguson 5300

Last Updated: June 2024

Overview

The Massey Ferguson 5300 is a utility tractor that was part of the 5000 series, manufactured from 2002 to 2006. It comes equipped with a robust Perkins 1004 turbocharged diesel engine rated at 95 horsepower and a displacement of 244 cubic inches. With a manual transmission featuring 18 forward and 6 reverse gears, this tractor offers flexibility in a variety of tasks. The tractor operates on a two-wheel-drive (2WD) chassis, with power steering for ease of maneuvering. The tractor's overall dimensions are 157.9 inches in length, 81.1 inches in width, and 104.7 inches in height, which partners with its operating weight of 7736 lbs for 2WD configurations and 8287 lbs for 4WD configurations to provide stable operations. This tractor also includes a Category 3 rear three-point hitch system, though other hydraulic and PTO details remain unknown. Its durable agricultural tires support routine tasks on the farm across different terrain.
Show more...

Key Specifications

Category: Utility

Power Output: 95

Transmission: Manual

Drive Type: 2WD

Operating Weight: 7736 (2WD) / 8287 (4WD)

Fuel Type: Diesel

Massey Ferguson 5300 vs. Similar Tractors

Power Output
Above Average
Greater than 80% of similar tractors.
Operating Weight
Excellent
Greater than 98% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
1004
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
244
Bore (in)
3.94
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
95

Transmission

Type
Manual
Forward Gears
18
Reverse Gears
6
Total Gears
-

Dimensions

Length (in)
157.9
Width (in)
81.1
Height (in)
104.7
Operating Weight (lb)
7736 (2WD) / 8287 (4WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
2006
Hitch Type
Three-Point Hitch
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
