Massey Ferguson 460 Xtra

Last Updated: June 2024

Overview

The Massey Ferguson 460 Xtra is a utility tractor designed to accommodate a variety of agricultural tasks. It is equipped with a 4x2 2WD chassis and powered by a 110 hp AGCO Sisu Power 420DS engine with a displacement of 268.5 ci. The engine is turbocharged, liquid-cooled, and employs a direct injection fuel system. Driving the tractor is facilitated by a 12-speed synchromesh transmission and hydrostatic power steering, providing smooth maneuverability and efficient field operations. With a wheelbase of 107.5 inches and an operating weight of 9,281 lbs, it is built robust and stable for challenging tasks. The tractor sports as standard agriculture tires, sized 9.00-16 at the front and 18.4-34 at the rear for the 2WD model. While specific details on the tractor’s starting year of manufacture, hitch capabilities, hydraulic system, and various other features are not provided, its built quality and power output suggest it's capable of handling demanding agricultural demands with reliability and efficiency.
Show more...

Key Specifications

Category: Utility

Power Output: 110

Transmission: Synchromesh

Drive Type: 2WD

Operating Weight: 9,281

Fuel Type: Diesel

Massey Ferguson 460 Xtra vs. Similar Tractors

Power Output
Above Average
Greater than 85% of similar tractors.
Operating Weight
Poor
Greater than 4% of similar tractors.

Technical Specifications

Engine

Manufacturer
AGCO Sisu Power
Model
420DS
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
268.5
Bore (in)
4.252
Stroke (in)
4.724
Rated RPM
-
Power Output (hp)
110

Transmission

Type
Synchromesh
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
182.3
Width (in)
-
Height (in)
103.9
Operating Weight (lb)
9,281

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag: Front: 9.00-16, Rear: 18.4-34 2WD)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
