Massey Ferguson 430

Last Updated: June 2024

Overview

The Massey Ferguson 430 is a utility tractor that offers a balance of functionality and simplicity. Manufactured by Massey Ferguson from 2002 to 2012, it features a 74 hp Perkins 1103C 33T turbocharged diesel engine with three cylinders. The tractor is powered by a liquid-cooled engine that offers substantial torque, rated at 214.6 lb-ft with a rated RPM of 2200. Geared for a variety of tasks, the tractor has an 8-speed synchro shuttle transmission enabling efficient forward and reverse movement. The design includes hydrostatic power steering, contributing to the machine's ease of maneuverability in diverse working conditions. The tractor could be configured in either two-wheel drive (2WD) with a wheelbase of 81.1 inches or with a four-wheel drive (4WD) option which extends the wheelbase to 83.5 inches. The operating weight varies from 5016 pounds in the 2WD ROPS configuration to 6338 pounds in the 4WD cab model, indicating its capacity to handle substantial loads and operational demands.
Show more...

Key Specifications

Category: Utility

Power Output: 74

Transmission: synchro shuttle

Drive Type: 2WD

Operating Weight: 5016 (2WD ROPS) to 6338 (4WD cab)

Fuel Type: diesel

Massey Ferguson 430 vs. Similar Tractors

Power Output
Average
Greater than 67% of similar tractors.
Operating Weight
Excellent
Greater than 96% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
1103C 33T
Cooling Type
liquid-cooled
Cylinder Orientation
inline
Valve Configuration
-
Fuel Type
diesel
Induction Type
turbocharged
Cylinders
3
Displacement (ci)
201.4
Bore (in)
4.134
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
74

Transmission

Type
synchro shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
138.2 (2WD), 140.9 (4WD)
Width (in)
-
Height (in)
93.7 (ROPS), 93.5 (cab)
Operating Weight (lb)
5016 (2WD ROPS) to 6338 (4WD cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
2012
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
electric
Brake Type
-
Hydraulic System Type
-
