Massey Ferguson 375

Last Updated: July 2024

Overview

The Massey Ferguson 375 is a utility tractor powered by a Perkins Diesel A4.236 four-cylinder engine with a rated power output of 58.1 HP at 2200 RPM. It has a maximum torque of 180.9 lb-ft at 1355 RPM and a torque rise of 21.9%. The engine displacement is 236 cubic inches. The tractor features a synchromesh transmission with 12 forward and 4 reverse gears, and is available in 2WD and 4WD configurations. The unladen operating weight is 7350 lbs. It has hydrostatic power steering, a three-point hitch with a maximum force exerted of 4270 lbs, and an open-center hydraulic system with a pump delivery rate of 8.7 GPM at minimum pressure and 8.0 GPM at maximum hydraulic power of 13.8 HP at 2975 psi. The tractor is fitted with rear tires of size 16.9-30 at 12 psi and front tires of size 7.50-16 at 26 psi. Additional performance details, such as fuel consumption, drawbar power, sound levels, and PTO speeds, are provided.
Show more...

Key Specifications

Category: Utility

Power Output: 58.1

Transmission: Synchromesh with optional two-speed power shift

Drive Type: 2WD and 4WD

Operating Weight: 7350

Fuel Type: Diesel

Image Gallery

Massey Ferguson 375 Tractor Massey Ferguson 375 Tractor Massey Ferguson 375 Tractor Massey Ferguson 375 Tractor Massey Ferguson 375 Tractor Massey Ferguson 375 Tractor

Massey Ferguson 375 vs. Similar Tractors

Power Output
Average
Greater than 65% of similar tractors.
Hitch Capacity
Above Average
Greater than 72% of similar tractors.
Operating Weight
Above Average
Greater than 78% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins Diesel
Model
A4.236
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
4
Displacement (ci)
236
Bore (in)
3.878
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
58.1

Transmission

Type
Synchromesh with optional two-speed power shift
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
144.1 (2WD), 152.8 (4WD)
Width (in)
77.6 (2WD), 75.6 (4WD)
Height (in)
93.7 (2WD), 95.7 (4WD)
Operating Weight (lb)
7350

Power Take-Off (PTO)

PTO Type
Live or independent
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
540/1000
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD or 4x4 MFWD
Drive Type
2WD and 4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
16
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Rear: Two 16.9-30, 6-ply at 12 psi; Front: Two 7.50-16, 6-ply at 26 psi
Manufacture - End Year
1997
Hitch Type
Three-Point Hitch
Hitch Category
Category II
Hitch Position
Rear
Hitch Capacity (lb)
4270
Operator Station Type
Two-post ROPS
Starter Type
Electric
Brake Type
Multiple wet disc hydraulically operated brakes
Hydraulic System Type
Open center

Test Results

Nebraska Tractor Test Laboratory - Test Date: April to May, 1987 (Supplemental tests: November 1988 to January 1989)

Maximum Power and Fuel Consumption

  • Maximum Power: 58.1 HP (43.3 kW) at 2200 rpm
  • Fuel Consumption at Maximum Power: 3.80 Gal/hr (14.39 l/h) with a fuel efficiency of 0.455 lb/hp.hr (0.277 kg/kW.h)
  • Standard Power Take-off Speed (540 rpm): Achieved at 1893 rpm

Drawbar Performance

  • Maximum Drawbar Power: 50.6 HP (37.7 kW) in 8th Gear (Hi range)
  • Fuel Consumption at 75% Pull at Maximum Power in 8th Gear: 11.52 Hp.hr/gal (2.27 kW.h/l) with a fuel consumption of 0.603 lb/hp.hr (0.367 kg/kW.h)
  • Fuel Consumption at 50% Pull at Maximum Power in 8th Gear: 9.29 Hp.hr/gal (1.83 kW.h/l) with a fuel consumption of 0.750 lb/hp.hr (0.456 kg/kW.h)

Torque and Engine Performance

  • Maximum Torque: 180.9 lb.-ft. (2453 Nm) at 1355 rpm
  • Torque Rise: 21.9%

Hydraulic Performance

  • Maximum Force Exerted: 14250 lbs (63.4 kN)
  • Pump Delivery Rate: 8.7 GPM (33.1 l/min) at minimum pressure
  • Hydraulic Power: 13.8 HP (10.3 kW) at delivery pressure of 2975 psi (205 bar)



Nebraska Tractor Test Lab. (1988). Nebraska Summary: S031 Massey Ferguson 375. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/2657
