Massey Ferguson 3708F

Last Updated: June 2024

Overview

The Massey Ferguson 3708F is an Orchard/Vineyard category tractor designed for specialty farming tasks. It offers 4WD capability with a 4x4 MFWD drive layout and is steered via a power-assisted system. The tractor is powered by a 4-cylinder liquid-cooled diesel engine with a displacement of 207.5 cubic inches, delivering up to 85 horsepower according to the European Council Directive 97/68/EC or 80 horsepower as noted by CEG. The common-rail injection system ensures efficient fuel delivery. This model offers versatility in transmission options with a 12-speed or 24-speed mechanical shuttle, or a power shuttle with 24 forward gears and 12 reverse gears. The 3708F model began its production in 2017 and features a wheelbase of 83.6 inches with a length of 156.9 inches and a width of 57.1 inches. However, detailed specs like operator station type, brake and hydraulic system types, and lifting capacities for the hitch remain unspecified based on the data provided.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 85 (Manufacturer's claim), 80 (CEG Gross Power)

Drive Type: 4WD

Fuel Type: Diesel

Massey Ferguson 3708F vs. Similar Tractors

Power Output
Average
Greater than 63% of similar tractors.

Technical Specifications

Engine

Manufacturer
-
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Common rail injection
Cylinders
4
Displacement (ci)
207.5
Bore (in)
-
Stroke (in)
-
Rated RPM
-
Power Output (hp)
85 (Manufacturer's claim), 80 (CEG Gross Power)

Transmission

Type
-
Forward Gears
24
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
156.9
Width (in)
57.1
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
II/I
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
