Massey Ferguson 3650F

Last Updated: June 2024

Overview

The Massey Ferguson 3650F is a utility tractor that was part of the 3600 series manufactured from 2011 to 2017. It is geared with a hydrostatic power steering system and powered by a liquid-cooled AGCO Power 33CTA diesel engine with a displacement of 201 cubic inches. The engine produces 94 horsepower at a rated RPM of 2200. This model features a mechanical shuttle/power shuttle transmission with 24 forward and 12 reverse gears, which hints at its capability to handle different work tasks efficiently. The tractor operates on a 4x2 2WD chassis and has an operating weight range of 6085 to 6559 pounds, varying with the presence of ROPS (Roll-Over Protection Structure) or a cab. The dimensions include a length of 156.9 inches, a width of 57.1 inches, and a height of 90.6 inches. Engine details like cylinder orientation, valve configuration, coolant capacity, and specific tire sizes were not available in the data provided.
Show more...

Key Specifications

Category: Utility

Power Output: 94

Transmission: Mechanical shuttle / Power shuttle

Drive Type: 2WD

Operating Weight: 6085 (4WD ROPS) / 6559 (4WD Cab)

Fuel Type: Diesel

Image Gallery

Massey Ferguson 3650F Tractor Massey Ferguson 3650F Tractor Massey Ferguson 3650F Tractor Massey Ferguson 3650F Tractor Massey Ferguson 3650F Tractor Massey Ferguson 3650F Tractor Massey Ferguson 3650F Tractor Massey Ferguson 3650F Tractor

Massey Ferguson 3650F vs. Similar Tractors

Power Output
Above Average
Greater than 78% of similar tractors.
Operating Weight
Excellent
Greater than 97% of similar tractors.

Technical Specifications

Engine

Manufacturer
AGCO Power
Model
33CTA
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Common rail direct injection
Cylinders
3
Displacement (ci)
201
Bore (in)
4.252
Stroke (in)
4.724
Rated RPM
2200
Power Output (hp)
94

Transmission

Type
Mechanical shuttle / Power shuttle
Forward Gears
24
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
156.9
Width (in)
57.1
Height (in)
90.6
Operating Weight (lb)
6085 (4WD ROPS) / 6559 (4WD Cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
2017
Hitch Type
II/I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
