Massey Ferguson 3650A

Last Updated: June 2024

Overview

The Massey Ferguson 3650A is a utility tractor that was designed to cater to a variety of tasks in the agricultural sector. With a chassis configuration of 4x2 2WD, it is capable of handling a wide range of moderate field work. This model is equipped with a hydrostatic power steering system, enhancing maneuverability and ease of operation. At the heart of this tractor is a robust AGCO Power 33CTA diesel engine with a displacement of 201 cubic inches, delivering a rated power output of 92 horsepower. The engine operates at a rated RPM of 2200, and features a liquid cooling system to maintain optimum temperature during heavy workloads. The tractor's power is harnessed through a power shuttle transmission with 24 forward and 12 reverse gears, providing flexibility for various tasks. In terms of physical dimensions, the Massey Ferguson 3650A measures 147.3 inches in length, 65 inches in width, and stands 98.8 inches tall when equipped with a cab. This model exhibits a weight range of 6239 to 7187 pounds, depending on the chosen configurations and additional equipment. The tractor's flexibility is further showcased by its capability to accommodate different tire sizes, compatible with both 2WD and 4WD setups, allowing for customized traction in various farming conditions.
Show more...

Key Specifications

Category: Utility

Power Output: 92

Transmission: Power shuttle

Drive Type: 2WD

Operating Weight: 6239 to 7187

Fuel Type: Diesel

Massey Ferguson 3650A vs. Similar Tractors

Power Output
Above Average
Greater than 77% of similar tractors.
Operating Weight
Above Average
Greater than 90% of similar tractors.

Technical Specifications

Engine

Manufacturer
AGCO Power
Model
33CTA
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Common rail direct injection
Cylinders
3
Displacement (ci)
201
Bore (in)
4.252
Stroke (in)
4.724
Rated RPM
2200
Power Output (hp)
92

Transmission

Type
Power shuttle
Forward Gears
24
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
147.3
Width (in)
65
Height (in)
98.8
Operating Weight (lb)
6239 to 7187

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard tires (ag)
Manufacture - End Year
-
Hitch Type
II/I
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
