Massey Ferguson 3315

Last Updated: June 2024

Overview

The Massey Ferguson 3315 is an orchard/vineyard style tractor designed for specialized agricultural tasks. It comes equipped with a Perkins 903.27 three-cylinder, four-stroke liquid-cooled diesel, 164 cubic inch engine. This 55 hp engine operates at 2250 rated RPM and is capable of producing 141.6 lb-ft of torque at 1250 RPM. The tractor is available in a standard two-wheel-drive (2WD) configuration with various tire options depending on specific models (3315V, 3315S, 3315F, 3315FE, 3315GE) affecting its width. The power steering and optional cab or ROPS configurations provide comfort and safety for the operator. Its hydraulic system is of an open center type, and while it features a heavy-duty hitch system, specifics regarding its lift capacity are not detailed. Overall dimensions suggest a relatively compact tractor with a notable range in weight depending on the model and configuration. Transmission options include a variety of sync shuttle and power shift gears with a potential of up to 36 forward and reverse gears.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 55

Transmission: Sync shuttle / Power shift

Drive Type: 2WD

Operating Weight: 4409 (2WD ROPS) to 5071 (4WD Cab)

Fuel Type: Diesel

Massey Ferguson 3315 vs. Similar Tractors

Power Output
Below Average
Greater than 28% of similar tractors.
Operating Weight
Excellent
Greater than 95% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
903.27
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
164
Bore (in)
3.74
Stroke (in)
5
Rated RPM
2250
Power Output (hp)
55

Transmission

Type
Sync shuttle / Power shift
Forward Gears
36
Reverse Gears
36
Total Gears
-

Dimensions

Length (in)
147.6
Width (in)
39.4 (Model 3315V) / 47.2 (Model 3315S) / 55.1 (Model 3315F) / 55.1 (Model 3315FE) / 50.4 (Model 3315GE)
Height (in)
49.2 (Steering wheel) / 86.6 (ROPS) / 85.4 (Cab)
Operating Weight (lb)
4409 (2WD ROPS) to 5071 (4WD Cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
28
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
II/I
Hitch Category
3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS / Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
