Massey Ferguson 3255

Last Updated: June 2024

Overview

The Massey Ferguson 3255 is an orchard/vineyard tractor known for its maneuverability and compatibility with various farming tasks. It employs a 95 horsepower Perkins 1004.40T turbocharged diesel engine, characterized by a liquid-cooled system and direct injection fuel system. This engine also features a thermostart pre-heating system with a high compression ratio of 17.25:1 for reliable cold-weather starts. The tractor's powerplant delivers a torque of 285.5 lb-ft at 1400 RPM. The MF 3255 is equipped with a partially synchronized 12-speed transmission allowing for a variety of working speeds and operational ease. The steering is power-assisted, enhancing control and reducing operator fatigue. While specifics like height and the wheelbase are provided, the tractor's overall width and operating weight are not detailed in the provided data. Additionally, exact capacities for fluids like coolant are not present, leaving some aspects of operation and maintenance to be clarified by additional resources or direct measurement.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 95

Transmission: Partially synchronized

Drive Type: 2WD

Fuel Type: Diesel

Massey Ferguson 3255 vs. Similar Tractors

Power Output
Above Average
Greater than 73% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
1004.40T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
243
Bore (in)
3.937
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
95

Transmission

Type
Partially synchronized
Forward Gears
12
Reverse Gears
-
Total Gears
12

Dimensions

Length (in)
159.1
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
Rear Type II
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
