Massey Ferguson 3245

Last Updated: June 2024

Overview

The Massey Ferguson 3245 is an orchard/vineyard tractor recognized for its efficiency in enclosed and narrow spaces. The 3245 has a 4x2 2WD chassis and is powered by a Perkins 1004.40T engine, which is turbocharged and liquid-cooled. It has a power output of 91 hp and a displacement of 243 cubic inches. This tractor is equipped with a power steering system and a partially synchronized transmission that offers 12 forward and reverse gears. The engine operates at a rated 2200 RPM and provides a maximum torque of 264 lb-ft at 1400 RPM. This model underwent various height configurations with a length of 159.1 inches and has standard agricultural tires. Specific information about hitch type and operating weight remains unknown, as well as the PTO and brake types. However, it features an open center hydraulic system and offers both ROPS and Cab configurations for the operator station.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 91

Transmission: Partially synchronized

Drive Type: 2WD

Fuel Type: Diesel

Massey Ferguson 3245 vs. Similar Tractors

Power Output
Average
Greater than 68% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
1004.40T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
243
Bore (in)
3.937
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
91

Transmission

Type
Partially synchronized
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
159.1
Width (in)
-
Height (in)
102 (ROPS)
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Unknown (Multiple types listed: ROPS, Cab)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
