Massey Ferguson 290

Last Updated: June 2024

Overview

The Massey Ferguson 290, available in both two-wheel drive (2WD) and four-wheel drive (4WD) configurations, was a versatile utility tractor produced by Massey Ferguson between 1983 and 1986. Equipped with a four-cylinder Perkins A4.248 diesel engine, the tractor was well-suited for a variety of tasks on the farm. It delivered 80 horsepower and had a displacement of 248 cubic inches. With options for manual or Multi-Power transmissions, operators could choose between a basic 8-forward and 2-reverse gear system, or a more advanced 12-forward and 4-reverse gear setup, which included a two-speed power shift. The Massey Ferguson 290 had a hydrostatic power-assisted steering system, providing easy and responsive handling. The tractor’s design embraced practicality, featuring an open operator station, with the option for an enclosed cabin, and a rugged, sturdy build for reliable farming operations.
Show more...

Key Specifications

Category: Utility

Power Output: 80

Transmission: Manual or Multi-Power partial power shift

Drive Type: 2WD or 4WD

Operating Weight: 5940

Fuel Type: Diesel

Massey Ferguson 290 vs. Similar Tractors

Power Output
Above Average
Greater than 71% of similar tractors.
Operating Weight
Average
Greater than 48% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
A4.248
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
248
Bore (in)
3.975
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
80

Transmission

Type
Manual or Multi-Power partial power shift
Forward Gears
8 (Manual), 12 (Multi-Power)
Reverse Gears
2 (Manual), 4 (Multi-Power)
Total Gears
-

Dimensions

Length (in)
151 (2WD), 153 (4WD)
Width (in)
85
Height (in)
70
Operating Weight (lb)
5940

Power Take-Off (PTO)

PTO Type
Rear, live type with dual clutch / independent (optional)
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
1000 (as an option with dual speed)
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD or 4x4 MFWD 4WD
Drive Type
2WD or 4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
12
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
1986
Hitch Type
Three-point
Hitch Category
II
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Open/Optional Cabin
Starter Type
Electric
Brake Type
Hydraulic wet discs
Hydraulic System Type
Open center
