Massey Ferguson 284SK

Last Updated: June 2024

Overview

The Massey Ferguson 284SK is a 4WD tractor, equipped with a robust Perkins A4.236 four-cylinder diesel engine, which delivers 68 horsepower. The tractor has a manual 12-speed transmission, with a total of 12 forward gears and four reverse gears, providing versatility in various agricultural tasks. A hydrostatic power steering system eases maneuverability. This tractor features agricultural tires with front dimensions of 12.4-24 inches and rear dimensions of 16.9-34 inches, enhancing its capability on different terrains. The tractor's wheelbase measures at 95.3 inches, offering stability, and it boasts an operating weight of 7,431 pounds which underscores its strength for heavier operations. Its length and height are 159.1 inches and 108.3 inches respectively, indicating a substantial size to tackle significant farm demands.
Show more...

Key Specifications

Power Output: 68

Transmission: manual

Drive Type: 4WD

Operating Weight: 7,431

Fuel Type: diesel

Technical Specifications

Engine

Manufacturer
Perkins
Model
A4.236
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
-
Cylinders
4
Displacement (ci)
235.5
Bore (in)
3.875
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
68

Transmission

Type
manual
Forward Gears
12
Reverse Gears
4
Total Gears
16

Dimensions

Length (in)
159.1
Width (in)
-
Height (in)
108.3
Operating Weight (lb)
7,431

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
24
Front Tire Width (in)
12.4
Rear Tire Diameter (in)
34
Rear Tire Width (in)
16.9
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
