Massey Ferguson 2706E

Last Updated: June 2024

Overview

The Massey Ferguson 2706E is a versatile utility tractor that was manufactured between 2016 and 2019. Fitted with a powerful 57.3 horsepower Shibaura turbocharged diesel engine, it operates efficiently at a rated RPM of 2600. The tractor offers two types of transmissions: an 8-speed synchro-shuttle and an infinite (3-range) hydrostatic transmission, giving the operator flexibility depending on the task at hand. The tractor's chassis is a 4x4 MFWD 4WD with power steering, contributing to its ease of maneuverability and control. It operates with an open center hydraulic system and possesses a lift capacity of 2425.1 pounds. With a wheelbase of 78 inches and a total operating weight ranging from 3847 to 3891 pounds, this model supports various tire setups for agricultural, lawn care, or industrial applications. It also features a rollover protection structure (ROPS) for operator safety and is equipped with a PTO system that is both electro-hydraulically engaged and live, running at a standard speed of 540 rpm.
Show more...

Key Specifications

Category: Utility

Power Output: 57.3

Transmission: Syncro-Shuttle / Hydrostatic

Drive Type: MFWD 4WD

Operating Weight: 3847 (Gear) / 3891 (Hydro)

Fuel Type: Diesel

Massey Ferguson 2706E vs. Similar Tractors

Power Output
Average
Greater than 55% of similar tractors.
Hitch Capacity
Average
Greater than 40% of similar tractors.
Operating Weight
Above Average
Greater than 86% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
N4LDI-TA
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
135.2
Bore (in)
3.307
Stroke (in)
3.937
Rated RPM
2600
Power Output (hp)
57.3

Transmission

Type
Syncro-Shuttle / Hydrostatic
Forward Gears
8 / Infinite (3-range)
Reverse Gears
8 / Infinite (3-range)
Total Gears
-

Dimensions

Length (in)
133
Width (in)
74
Height (in)
104
Operating Weight (lb)
3847 (Gear) / 3891 (Hydro)

Power Take-Off (PTO)

PTO Type
Electro-hydraulically engaged / Live
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD 4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag / Lawn/turf / Industrial
Manufacture - End Year
2019
Hitch Type
Three-Point Hitch
Hitch Category
II/I
Hitch Position
-
Hitch Capacity (lb)
2425.1 lbs
Operator Station Type
ROPS
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
