Massey Ferguson 2435

Last Updated: June 2024

Overview

The Massey Ferguson 2435 is a utility tractor that was part of the 2400 Series manufactured from 2005 to 2007. It features a Perkins 800 series turbocharged diesel engine with a displacement of 201 cubic inches and a rated power output of 75.1 hp at 2500 rpm. Equipped with a liquid cooling system, this four-cylinder engine delivers robust performance for a range of tasks. The tractor has a mechanical front-wheel drive (4x4 MFWD 4WD), enhanced by a two-speed power shift transmission facilitating 30 forward and reverse gears. A Category II hitch system is standard, situated at the rear of the tractor, with an operating weight of 6724 pounds. The physical dimensions of the Massey Ferguson 2435 reflect a length of 158.3 inches, a width of 74 inches, and a height of 94.5 inches when measured to the cab top. The standard agriculture tires are sized 12.4R20 in the front and 14.9R30 in the rear.
Show more...

Key Specifications

Category: Utility

Power Output: 75.1

Transmission: Two-speed power shift

Drive Type: 4WD

Operating Weight: 6724

Fuel Type: Diesel

Massey Ferguson 2435 vs. Similar Tractors

Power Output
Average
Greater than 68% of similar tractors.
Operating Weight
Average
Greater than 51% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
800
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
201
Bore (in)
3.7
Stroke (in)
4.72
Rated RPM
2500
Power Output (hp)
75.1

Transmission

Type
Two-speed power shift
Forward Gears
30
Reverse Gears
30
Total Gears
-

Dimensions

Length (in)
158.3
Width (in)
74
Height (in)
94.5
Operating Weight (lb)
6724

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard tires (ag)
Manufacture - End Year
2007
Hitch Type
Category II
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
