Massey Ferguson 2410

Last Updated: June 2024

Overview

The Massey Ferguson 2410, a model within the 2400 Series, is categorized as a compact utility tractor suitable for a variety of tasks on smaller properties and farms. Manufactured by Massey Ferguson, part of AGCO, from 2003 to 2008, it is powered by a 40 horsepower Mitsubishi turbocharged diesel engine with a liquid-cooling system. It boasts a 91.5 ci engine displacement and operates at a rated RPM of 3000, offering substantial torque of 74 lb-ft at 2100 RPM. Its four-wheel drive, mechanical four-wheel drive chassis provides good traction in various conditions. The power steering aids maneuverability, while the 12-speed mechanical shuttle transmission allows for a wide range of working speeds. This model comes with a weight of 2866 lbs and dimensions including a length of 120.3 inches and a height to the hood of 52.2 inches. While specifics around the hydraulic system, PTO speeds, and hitch details are not provided, it is known to have a Category I hitch. The tire configuration typically includes ag tires with front size 7.00-12 and rear size 320/70R20.
Show more...

Key Specifications

Category: Utility

Power Output: 40

Transmission: Mechanical shuttle

Drive Type: MFWD (Mechanical Front Wheel Drive) or 4WD

Operating Weight: 2866

Fuel Type: Diesel

Massey Ferguson 2410 vs. Similar Tractors

Power Output
Average
Greater than 37% of similar tractors.
Operating Weight
Below Average
Greater than 23% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
91.5
Bore (in)
-
Stroke (in)
-
Rated RPM
3000
Power Output (hp)
40

Transmission

Type
Mechanical shuttle
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
120.3
Width (in)
-
Height (in)
52.2 (hood)
Operating Weight (lb)
2866

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD (Mechanical Front Wheel Drive) or 4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2008
Hitch Type
-
Hitch Category
I
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
