Massey Ferguson 2230

Last Updated: September 2024

Overview

The Massey Ferguson 2230 is a versatile utility tractor built from 1999 to 2001. It features a powerful 4-cylinder Perkins diesel engine with 73 hp, making it well-suited for a variety of farm tasks. The engine's 258.3 ci displacement is above average for its class, providing good pulling power and performance.

This 4WD tractor offers excellent traction and maneuverability with its 4x4 MFWD chassis and power steering. The transmission is a Sync Shuttle with a two-speed power shift, offering 30 forward and 30 reverse gears for precise speed control. At 7,165 lb, it has an above-average operating weight, which contributes to its stability. The Massey Ferguson 2230 comes equipped with a Category II three-point hitch at the rear, an open center hydraulic system, and a ROPS operator station for safety. Its compact size, measuring 158.3 inches long, 77.9 inches wide, and 97.2 inches tall, makes it easy to maneuver in tight spaces while still providing ample power for most farming needs.
Show more...

Key Specifications

Category: Utility

Power Output: 73 hp (54.4 kW)

Transmission: Sync Shuttle / Two-speed power shift

Drive Type: 4WD

Operating Weight: 7165 lb (3250 kg)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Perkins
Model
1004-42
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
4
Displacement
258 ci (4.2 L)
Bore
4.05 in (103.0 mm)
Stroke
5.00 in (127.0 mm)
Rated RPM
2200
Power Output
73 hp (54.4 kW)

Transmission

Type
Sync Shuttle / Two-speed power shift
Forward Gears
30
Reverse Gears
30

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
