Massey Ferguson 1840E

Last Updated: June 2024

Overview

The Massey Ferguson 1840E is a compact utility tractor designed for a variety of agricultural tasks. It sports a 4x4 MFWD 4WD chassis, suitable for rough and variable terrain. Powered by a 39.4 horsepower turbocharged diesel engine built by Iseki, it provides ample power for its size. With a displacement of 111.4 cubic inches and a rated speed of 2600 RPM, it is engineered to handle demanding work. The versatile transmission options offer both an 8-speed mechanical shuttle and an infinite (3-range) hydrostatic system, simplifying operation with a choice between manual and automatic-like gear shifting. With power steering for maneuverability, this tractor is designed for ease of use. It measures 116.5 inches in length, 52.4 inches in width, and has a height of 97.6 inches, possessing a significant ground clearance of 11 inches. It has been in production since 2020 and holds an operating weight of 2877 pounds. The 1840E features an open-center hydraulic system, common for tractors of this size and capability. Additional specifications such as PTO speed and hitch capacity are not provided in the data. Overall, the Massey Ferguson 1840E is built to serve as a reliable workhorse for smaller-scale farming, landscaping, or estate management.
Show more...

Key Specifications

Category: Utility

Power Output: 39.4

Transmission: Mechanical shuttle / Hydrostatic

Drive Type: MFWD 4WD

Operating Weight: 2877

Fuel Type: Diesel

Massey Ferguson 1840E vs. Similar Tractors

Power Output
Average
Greater than 35% of similar tractors.
Operating Weight
Below Average
Greater than 24% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
Horizontal
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
111.4
Bore (in)
3.43
Stroke (in)
4.03
Rated RPM
2600
Power Output (hp)
39.4

Transmission

Type
Mechanical shuttle / Hydrostatic
Forward Gears
8 / Infinite (3-range)
Reverse Gears
8 / Infinite (3-range)
Total Gears
-

Dimensions

Length (in)
116.5
Width (in)
52.4
Height (in)
97.6
Operating Weight (lb)
2877

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD 4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
