Massey Ferguson 1835E

Last Updated: June 2024

Overview

The Massey Ferguson 1835E is a compact utility tractor designed for a variety of tasks. Equipped with a 34.5 horsepower Iseki engine, this tractor offers the power and efficiency needed for various agricultural duties. A notable feature is the turbocharged diesel engine with three cylinders and liquid-cooling system, ensuring reliable performance. Operating at a rated rpm of 2600, the engine meets Tier IV emissions standards. With a mechanical shuttle transmission featuring 8 forward and reverse gears, the 1835E provides versatility in handling different tasks. The tractor stands out with its 4x4 MFWD 4WD chassis, providing enhanced traction and stability across different terrains, and the hydraulic system features an open center type with a steering flow rate of 3.8 gpm. With a weight of 2877 lbs and measurements including a length of 116.5 inches, a width of 52.4 inches, and a height of 97.6 inches, it offers a compact yet sturdy framework suitable for various environments. The 1835E started its manufacture in the year 2020 with its end year still unknown and provides a solid first foray into the 1800E series.
Show more...

Key Specifications

Category: Utility

Power Output: 34.5

Drive Type: MFWD 4WD

Operating Weight: 2877

Fuel Type: Turbocharged diesel

Massey Ferguson 1835E vs. Similar Tractors

Power Output
Below Average
Greater than 30% of similar tractors.
Operating Weight
Below Average
Greater than 24% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Turbocharged diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
111.4
Bore (in)
3.43
Stroke (in)
4.03
Rated RPM
2600
Power Output (hp)
34.5

Transmission

Type
-
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
116.5
Width (in)
52.4
Height (in)
97.6
Operating Weight (lb)
2877

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD 4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
