Massey Ferguson 1552

Last Updated: June 2024

Overview

The Massey Ferguson 1552 is a compact utility tractor that was manufactured by Iseki between 2005 and 2008. This model is designed with a 4x2 2WD chassis, and houses a four-cylinder Iseki diesel engine with a displacement of 180 cubic inches, which generates a gross horsepower of 52 at 2500 RPM. It has a liquid-cooling system and a total coolant capacity of 8 quarts. The tractor comes with the option of three different types of transmissions: SynchroShuttle, PowerShuttle, and DynaQPS PowerShuttle, all providing 12 forward and reverse gears respectively. The 1552 has a wheelbase of 75 inches, with an overall length of 132.7 inches, width of 66.1 inches, and height of 90.7 inches. The operating weight ranges from 3663 to 4023 pounds, which includes both rollover protection system (ROPS) and cab variants. The Category 3 three-point hitch has a lift capacity of 3483.4 pounds at 24 inches behind the link arms. This tractor offers a good balance between capability and size, making it suitable for a variety of tasks in a compact or suburban farming environment.
Show more...

Key Specifications

Category: Utility

Power Output: 52

Transmission: SynchroShuttle, PowerShuttle, DynaQPS PowerShuttle

Drive Type: 2WD

Operating Weight: 3663 to 4023

Fuel Type: Diesel

Massey Ferguson 1552 vs. Similar Tractors

Power Output
Average
Greater than 50% of similar tractors.
Hitch Capacity
Average
Greater than 63% of similar tractors.
Operating Weight
Above Average
Greater than 85% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
180
Bore (in)
3.82
Stroke (in)
3.94
Rated RPM
2500
Power Output (hp)
52

Transmission

Type
SynchroShuttle, PowerShuttle, DynaQPS PowerShuttle
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
132.7
Width (in)
66.1
Height (in)
90.7
Operating Weight (lb)
3663 to 4023

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
8
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
2008
Hitch Type
Cat I
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
3483.4 lbs @ 24 inches
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
