Massey Ferguson 152V

Last Updated: June 2024

Overview

The Massey Ferguson 152V is a utility tractor known for its reliable performance and adaptability for various farming tasks. It features a robust diesel engine, the Perkins 3-152S, with a displacement of 152.7 cubic inches, delivering 50.3 horsepower at 2250 RPM. This model uses a liquid-cooled system to maintain engine temperature and a gear-driven transmission with 8 forward and 2 reverse gears, facilitating a range of working speeds. The tractor accommodates agricultural tires but exact tire dimensions are not specified in the data provided. Its dimensions create a relatively compact footprint with a length of 109.5 inches, width of 43.3 inches, and a height of 53.9 inches to the steering wheel. The operating weight is listed at 3748 pounds. The Massey Ferguson 152V is equipped with a Category I 3-point hitch, allowing for easy attachment of implements. The steering type, hydraulic system details, operator station type, and PTO specifics are not provided in the dataset. The front and rear tread are adjustable, offering customization for different row widths. With its electric starter and 12-volt system, the tractor ensures efficient ignition in various conditions.
Show more...

Key Specifications

Category: Utility

Power Output: 50.3

Transmission: Gear

Drive Type: 2WD

Operating Weight: 3748

Fuel Type: Diesel

Massey Ferguson 152V vs. Similar Tractors

Power Output
Average
Greater than 49% of similar tractors.
Operating Weight
Average
Greater than 33% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
3-152S
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
3
Displacement (ci)
152.7
Bore (in)
3.6
Stroke (in)
5
Rated RPM
2250
Power Output (hp)
50.3

Transmission

Type
Gear
Forward Gears
8
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
109.5
Width (in)
43.3
Height (in)
53.9
Operating Weight (lb)
3748

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category I 3-point hitch
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
