Massey Ferguson 1528

Last Updated: June 2024

Overview

The Massey Ferguson 1528 is a compact utility tractor that was manufactured between 2005 and 2010. It features a 4x4 MFWD 4WD chassis design, providing better traction and power for various tasks. The tractor is equipped with two types of transmission: a 9-speed gear and a hydrostatic option, offering versatility for the operator. Powered by a diesel, 3-cylinder Iseki liquid-cooled engine with a displacement of 89.3 cubic inches, it delivers a gross power output of 28.4 horsepower at 2500 RPM. The tractor has an operating weight of 2423 pounds and can handle a hitch lift capacity of 2425.1 pounds at 24 inches. It offers multiple tire setups for different work environments, including standard, lawn/turf, and industrial configurations.
Show more...

Key Specifications

Category: Utility

Power Output: 28.4

Transmission: 9-speed gear and hydrostatic

Drive Type: 4WD

Operating Weight: 2423

Fuel Type: Diesel

Image Gallery

Massey Ferguson 1528 Tractor Massey Ferguson 1528 Tractor Massey Ferguson 1528 Tractor Massey Ferguson 1528 Tractor Massey Ferguson 1528 Tractor Massey Ferguson 1528 Tractor Massey Ferguson 1528 Tractor Massey Ferguson 1528 Tractor

Massey Ferguson 1528 vs. Similar Tractors

Power Output
Below Average
Greater than 23% of similar tractors.
Hitch Capacity
Average
Greater than 41% of similar tractors.
Operating Weight
Below Average
Greater than 19% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
89.3
Bore (in)
3.39
Stroke (in)
3.31
Rated RPM
2500
Power Output (hp)
28.4

Transmission

Type
9-speed gear and hydrostatic
Forward Gears
9
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
112.4
Width (in)
53.5
Height (in)
80.7
Operating Weight (lb)
2423

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
5.8
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag): Front: 7x14, Rear: 9.5x24; Lawn/turf: Front: 24x8.50-14, Rear: 36x13.5-15; Industrial: Front: 25x8.50-14, Rear: 12.50/80-18
Manufacture - End Year
2010
Hitch Type
Category 1
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
2425.1 lbs @ 24 inches
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
