Massey Ferguson 1433

Last Updated: June 2024

Overview

The Massey Ferguson 1433 is a compact utility tractor that was manufactured between 2002 and 2005. It features a 33 hp Iseki diesel engine with a liquid cooling system and indirect injection. The tractor has multiple transmission options available, including SynchroShuttle, PowerShuttle, and hydrostatic transmissions, providing a choice of either 16 synchronized gears in forward and reverse or infinite gear ranges with the hydrostatic model. It has power steering, a 91.4 cubic inch engine, and operates at 2600 rated RPM. The tractor is designed with a foldable ROPS for safety and a Category I rear hitch. The model is suitable for a variety of tasks in a compact or specialized setting, such as small farms or as a utility tractor in larger operations.
Show more...

Key Specifications

Category: Utility

Power Output: 33 hp

Transmission: SynchroShuttle, PowerShuttle, hydrostatic (multiple options available)

Operating Weight: 2810

Fuel Type: diesel

Image Gallery

Massey Ferguson 1433 Tractor Massey Ferguson 1433 Tractor Massey Ferguson 1433 Tractor Massey Ferguson 1433 Tractor Massey Ferguson 1433 Tractor Massey Ferguson 1433 Tractor

Massey Ferguson 1433 vs. Similar Tractors

Power Output
Below Average
Greater than 29% of similar tractors.
Operating Weight
Below Average
Greater than 23% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
-
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
indirect injection
Cylinders
3-cylinder
Displacement (ci)
91.4 ci
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
33 hp

Transmission

Type
SynchroShuttle, PowerShuttle, hydrostatic (multiple options available)
Forward Gears
16 (SynchroShuttle and PowerShuttle), infinite (hydrostatic)
Reverse Gears
16 (SynchroShuttle and PowerShuttle), infinite (hydrostatic)
Total Gears
-

Dimensions

Length (in)
121.5
Width (in)
55.5
Height (in)
92.5 (ROPS), 69.3 (Folded ROPS)
Operating Weight (lb)
2810

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Power (implied from steering flow availability)
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
19.5
Rear Tire Width (in)
15
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2005
Hitch Type
-
Hitch Category
Category I
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS (Roll Over Protection Structure)
Starter Type
Electric (implied from starter volts)
Brake Type
-
Hydraulic System Type
Open Center
