Massey Ferguson 1429

Last Updated: June 2024

Overview

The Massey Ferguson 1429 is a compact utility tractor that was manufactured by Iseki for Massey Ferguson between the years 2002 and 2005. This model is equipped with a four-wheel drive (4WD) chassis, providing enhanced traction and capability for a variety of agricultural tasks. It is powered by an Iseki 1.5L 3-cylinder liquid-cooled diesel engine that delivers 28.4 horsepower, paired with a SynchroShuttle and PowerShuttle transmission each offering 8 forward and reverse gears. The tractor supports power steering and features an open center hydraulic system. Weighing in at 2734 lbs, it has a wheelbase of 68.5 inches. The tractor comes with a Category I hitch system and a minimum width of 54.9 inches, allowing for operation in various conditions. Although the tractor is equipped with numerous features that support its operation within the compact utility category, detailed specifics about some aspects, such as tire dimensions, PTO, and cooling capacity, remain unknown.
Show more...

Key Specifications

Category: Utility

Power Output: 28.4

Drive Type: 4WD

Operating Weight: 2734

Fuel Type: Diesel

Massey Ferguson 1429 vs. Similar Tractors

Power Output
Below Average
Greater than 23% of similar tractors.
Operating Weight
Below Average
Greater than 22% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Indirect injection
Cylinders
3
Displacement (ci)
89.3
Bore (in)
-
Stroke (in)
-
Rated RPM
2500
Power Output (hp)
28.4

Transmission

Type
-
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
121.5
Width (in)
54.9 (min)
Height (in)
85.8 (with ROPS)
Operating Weight (lb)
2734

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag rear: Unknown, Industrial front: Unknown
Manufacture - End Year
2005
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
12 volts
Brake Type
-
Hydraulic System Type
Open center
