Massey Ferguson 1335

Last Updated: June 2024

Overview

The Massey Ferguson 1335 compact utility tractor, produced from 2002 to 2004, is designed as a versatile workhorse suitable for a variety of tasks. Equipped with a 4-wheel drive (4WD), four-wheel drive (MFWD) chassis, and a Mitsubishi 4-cylinder liquid-cooled engine rated at 35 horsepower and 3000 RPM, this tractor is poised to handle both small farming and general property maintenance tasks effectively. It has a steering wheel height of 48.8 inches and a hood height of 45.1 inches, providing a user-friendly operating environment. Its operating weight of 2513 lbs helps ensure stability across a range of operations, and it maintains a wheelbase of 64.2 inches, which contributes to balanced maneuverability. With hydrostatic power steering and a 12-speed mechanical shuttle transmission, the operator can expect ease of use and efficient power delivery when performing tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 35

Transmission: Mechanical shuttle

Drive Type: 4WD

Operating Weight: 2513

Massey Ferguson 1335 vs. Similar Tractors

Power Output
Average
Greater than 32% of similar tractors.
Operating Weight
Below Average
Greater than 20% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
-
Cylinders
4
Displacement (ci)
-
Bore (in)
-
Stroke (in)
-
Rated RPM
3000
Power Output (hp)
35

Transmission

Type
Mechanical shuttle
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
105.9
Width (in)
-
Height (in)
48.8 (steering wheel), 45.1 (hood)
Operating Weight (lb)
2513

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
Unknown (Uses standard 7.00-12 size)
Front Tire Width (in)
Unknown (Uses standard 7.00-12 size)
Rear Tire Diameter (in)
Unknown (Uses standard 320/70R20 size)
Rear Tire Width (in)
Unknown (Uses standard 320/70R20 size)
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural (standard); Lawn/turf (optional)
Manufacture - End Year
2004
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
