Massey Ferguson 1040

Last Updated: June 2024

Overview

The Massey Ferguson 1040 is a utility tractor with a focus on agricultural tasks. It is powered by a Toyosha 3D200 3-cylinder diesel engine, providing 32 horsepower with a displacement of 121.7 cubic inches. Equipped with power steering and a liquid-cooled engine, this model also features a gear transmission with 12 forward and 3 reverse gears, as well as a 540 rpm rear PTO for driving implements. The tractor's operating weight is around 3350 pounds for the 2WD configuration, and it supports standard agricultural tires with a 5.50-inch width in the front and a 13.6-inch width in the rear. At 115 inches in length, 58.5 inches in width, and a steering wheel height of 60.4 inches, the Massey Ferguson 1040 offers an open operator station, catering to a range of tasks on the farm or homestead with simplicity and reliability at its core.
Show more...

Key Specifications

Category: Utility

Power Output: 32

Transmission: Gear

Drive Type: 2WD (Assumption based on standard tire specification)

Operating Weight: 3350 (for 2WD model)

Fuel Type: Diesel

Image Gallery

Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor Massey Ferguson 1040 Tractor

Massey Ferguson 1040 vs. Similar Tractors

Power Output
Below Average
Greater than 27% of similar tractors.
Operating Weight
Above Average
Greater than 73% of similar tractors.

Technical Specifications

Engine

Manufacturer
Toyosha
Model
3D200
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
3
Displacement (ci)
121.7
Bore (in)
3.622
Stroke (in)
3.937
Rated RPM
2500
Power Output (hp)
32

Transmission

Type
Gear
Forward Gears
12
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
115
Width (in)
58.5
Height (in)
60.4 (Specified for the steering wheel height)
Operating Weight (lb)
3350 (for 2WD model)

Power Take-Off (PTO)

PTO Type
Standard (Assumption based on the rear PTO Type of 540)
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 (Assumption based on the rear tire specification, indicative of 2WD models)
Drive Type
2WD (Assumption based on standard tire specification)
Steering Type
Power
Coolant Capacity (qts)
8.5
Front Tire Diameter (in)
Unknown (Specification not provided and not inferable from width alone)
Front Tire Width (in)
5.5
Rear Tire Diameter (in)
Unknown (Specification not provided and not inferable from width alone)
Rear Tire Width (in)
13.6
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (agricultural)
Manufacture - End Year
-
Hitch Type
Type I
Hitch Category
Unknown (Type I is not the same as Category 3, which is typically for larger tractors)
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Open
Starter Type
Electric (Based on the starter volts specification)
Brake Type
-
Hydraulic System Type
Open Center
