Marshall 264

Last Updated: June 2024

Overview

The Marshall 264 is a compact utility tractor designed for a variety of tasks on a small farm or homestead. Equipped with a 4-wheel drive chassis (4x4 MFWD), it provides good traction for dealing with difficult terrain. The tractor comes with manual steering and operates with a standard transmission sporting a total of 12 forward gears and 6 reverse gears, indicative of a 6-speed gear system with high and low ranges. Under the hood lies a Lombardini 9LD561-2 diesel engine, which is a 2-cylinder air-cooled unit with a displacement of 68.4 cubic inches. The engine has a power output of 25.8 horsepower and runs at a rated 3000 RPM. In terms of physical dimensions, it's relatively diminutive at 86 inches long, 39.4 inches wide, and 46.5 inches tall, with an operating weight of 1545 pounds. The tractor rides on agricultural tires, 6.00-12 in front and 8.25-16 in the rear, which pair with its 54.2-inch wheelbase to provide stable operation. The Marshall 264's open operator station and basic hitch system suggest that it's intended for straightforward, no-frills agricultural work.
Show more...

Key Specifications

Category: Utility

Power Output: 25.8

Transmission: Gear

Drive Type: 4WD

Operating Weight: 1545

Fuel Type: Diesel

Marshall 264 vs. Similar Tractors

Power Output
Below Average
Greater than 19% of similar tractors.
Operating Weight
Below Average
Greater than 12% of similar tractors.

Technical Specifications

Engine

Manufacturer
Lombardini
Model
9LD561-2
Cooling Type
Air-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
2
Displacement (ci)
68.4
Bore (in)
3.54
Stroke (in)
3.46
Rated RPM
3000
Power Output (hp)
25.8

Transmission

Type
Gear
Forward Gears
12
Reverse Gears
6
Total Gears
-

Dimensions

Length (in)
86
Width (in)
39.4
Height (in)
46.5
Operating Weight (lb)
1545

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Manual
Coolant Capacity (qts)
Unknown (air-cooled engine typically does not have a coolant capacity)
Front Tire Diameter (in)
12
Front Tire Width (in)
6
Rear Tire Diameter (in)
16
Rear Tire Width (in)
8.25
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Open
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
