LS XU6168

Last Updated: June 2024

Overview

The LS XU6168 is a utility tractor that comes equipped with a four-wheel drive 4x4 MFWD 4WD chassis and power steering for efficient maneuverability and control across diverse terrains. The power is provided by a 68 hp turbocharged diesel engine with a liquid cooling system. At a rated RPM of 2500, this tractor is designed to handle various agricultural tasks with an engine displacement of 152.8 cubic inches. This practical workhorse offers a 16-speed synchronized shuttle and power shuttle transmission, accommodating a multitude of operations with 16 forward and reverse gears. It provides a comfortable operating station available with either a ROPS or a cab configuration, depending on the operator's needs. Though specific tractor dimensions like tire sizes and hitch lift capacity were not available, it offers a robust three-point hitch of Category II. With longevity in mind, this tractor caters to the demanding requirements of modern farming practices.
Show more...

Key Specifications

Category: Utility

Power Output: 68

Transmission: Synchronized shuttle and power shuttle

Drive Type: MFWD - Mechanical Front Wheel Drive

Operating Weight: 4674 (ROPS), 5121 (cab)

Fuel Type: Diesel

LS XU6168 vs. Similar Tractors

Power Output
Average
Greater than 63% of similar tractors.
Operating Weight
Average
Greater than 42% of similar tractors.

Technical Specifications

Engine

Manufacturer
LS
Model
L4C25-T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
152.8
Bore (in)
3.46
Stroke (in)
4.06
Rated RPM
2500
Power Output (hp)
68

Transmission

Type
Synchronized shuttle and power shuttle
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
138.6
Width (in)
70
Height (in)
103 (ROPS), 100.6 (cab)
Operating Weight (lb)
4674 (ROPS), 5121 (cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD - Mechanical Front Wheel Drive
Steering Type
Power steering
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag: Agricultural, Lawn/turf, Industrial
Manufacture - End Year
-
Hitch Type
Category II Three-Point Hitch
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS, Cab
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
Open center
