LS XJ2025

Last Updated: June 2024

Overview

The LS XJ2025 is a compact utility tractor equipped with a Mitsubishi S3L2 three-cylinder diesel engine, delivering 24.4 horsepower. It has a displacement of 80.4 cubic inches and operates at a rated RPM of 2500. The tractor can cater to various tasks with its available gear and hydrostatic transmission options, featuring 6 forward and 2 reverse gears for the gear model. The tractor's 4x4 chassis ensures improved traction and performance on different terrains. It offers both power steering capabilities, ensuring ease of maneuverability. This model supports different tire types, including Lawn/Turf and Industrial, providing flexibility for usage on multiple surfaces. With an operating weight between 1609 to 1785 pounds, it displays a robust build suitable for various agricultural applications. The tractor maintains user comfort with a ROPS-type operator station and the convenience of an electric starter. Moreover, it adheres to Tier IV emissions standards, making it an environmentally friendly choice in the compact tractor segment.
Show more...

Key Specifications

Category: Utility

Power Output: 24.4

Transmission: Hydrostatic and Gear

Drive Type: MFWD 4WD

Operating Weight: 1609 (Hydro) / 1785 (Gear)

Fuel Type: Diesel

LS XJ2025 vs. Similar Tractors

Power Output
Below Average
Greater than 16% of similar tractors.
Operating Weight
Above Average
Greater than 81% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S3L2
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Indirect Injection
Cylinders
3
Displacement (ci)
80.4
Bore (in)
3.07
Stroke (in)
3.62
Rated RPM
2500
Power Output (hp)
24.4

Transmission

Type
Hydrostatic and Gear
Forward Gears
6
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
103
Width (in)
44.9
Height (in)
92.3
Operating Weight (lb)
1609 (Hydro) / 1785 (Gear)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD 4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
23 (Lawn/Turf) / 23 (Industrial)
Front Tire Width (in)
8.5 (Lawn/Turf) / 8.5 (Industrial)
Rear Tire Diameter (in)
33 (Lawn/Turf) / 33 (Industrial)
Rear Tire Width (in)
12.5 (Lawn/Turf) / 12 (Industrial)
Front/Rear Rim Diameter (in)
-
Tire Type
Lawn/Turf, Industrial
Manufacture - End Year
-
Hitch Type
-
Hitch Category
I
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
