LS XG3037

Last Updated: June 2024

Overview

The LS XG3037 is a compact utility tractor that is designed with versatility and performance in mind. Its 4x4 MFWD 4WD chassis combined with power steering provides excellent maneuverability and traction across a variety of ground conditions. The tractor is equipped with a Shibaura N843T, a 3-cylinder turbocharged diesel engine that yields 36.2 horsepower with a displacement of 91.3 cubic inches. The engine operates at a rated RPM of 2600 and offers a torque of 82.6 lb-ft at 1600 RPM. The LS XG3037 can be outfitted with different tire types, including agricultural, lawn/turf, and industrial, depending on the tasks at hand. The tractor's dimensions and weight make it substantial enough for tough jobs while still maintaining a relatively compact footprint for its class. Operator comfort is ensured with the ROPS system in place and the electric starter facilitates reliable ignition. While the transmission comes in both 12-speed sync shuttle and an infinite (3-range) hydrostatic version, the LS XG3037's exact transmission setup for this model remains unclear, as both types are mentioned. However, given the available information, it is likely that buyers can choose between these transmission types when purchasing the tractor. The hydraulic system is open center, and the tractor's steering and other operations are supported by adequate flow rates, making it a robust choice for a wide range of agricultural tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 36.2

Transmission: Sync shuttle and hydrostatic

Drive Type: 4WD

Operating Weight: Gear: 2882 | Hydro: 2855

Fuel Type: Turbocharged diesel

LS XG3037 vs. Similar Tractors

Power Output
Average
Greater than 33% of similar tractors.
Operating Weight
Above Average
Greater than 84% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
N843T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Turbocharged diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
91.3
Bore (in)
3.31
Stroke (in)
3.54
Rated RPM
2600
Power Output (hp)
36.2

Transmission

Type
Sync shuttle and hydrostatic
Forward Gears
12 forward
Reverse Gears
12 reverse
Total Gears
-

Dimensions

Length (in)
123
Width (in)
55.5
Height (in)
89
Operating Weight (lb)
Gear: 2882 | Hydro: 2855

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag: Front 7-14, Rear 11.2-24 | Turf: Front 25x8.5-14, Rear 41x14-20 | Industrial: Front 25x8.5-14, Rear 43x16-20
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
