LS R4020H

Last Updated: June 2024

Overview

The LS R4020H is a compact utility tractor that offers a blend of power and versatility. With a liquid-cooled 47 horsepower Mitsubishi S4QL diesel engine, the tractor is capable of handling a variety of tasks. Its hydrostatic transmission with infinite (3-range) forward and reverse gears provides precise control and ease of use. The 4x4 MFWD 4WD chassis and hydrostatic power steering offer superior maneuverability. This particular model features a variety of tire options depending on the application, including agricultural, lawn/turf, and industrial types. It also boasts a spacious length of 132.2 inches, a moderate width of 55.9 inches, and a height of 95.1 inches when equipped with a Roll-Over Protection System (ROPS). Weighing at 3813 lbs, the R4020H has a substantial presence, emphasizing stability and durability. The information provided suggests a robust tractor designed for a variety of utility tasks in a compact package.
Show more...

Key Specifications

Category: Utility

Power Output: 47

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 3813

Fuel Type: Diesel

LS R4020H vs. Similar Tractors

Power Output
Average
Greater than 45% of similar tractors.
Operating Weight
Average
Greater than 34% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4QL
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Indirect injection
Cylinders
4
Displacement (ci)
152.9
Bore (in)
3.46
Stroke (in)
4.06
Rated RPM
2600
Power Output (hp)
47

Transmission

Type
Hydrostatic
Forward Gears
Infinite (3-range)
Reverse Gears
Infinite (3-range)
Total Gears
-

Dimensions

Length (in)
132.2
Width (in)
55.9
Height (in)
95.1
Operating Weight (lb)
3813

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag: Front: 9.5x16, Rear: 12.4x24, Lawn/turf front: 28x8.5-15, Lawn/turf rear: 41x14-20, Industrial front: 10x16.5, Industrial rear: 43x14-20.4
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 1
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
