LS R3039H

Last Updated: June 2024

Overview

The LS R3039H is a compact utility tractor that is designed with a 4x4 MFWD 4WD chassis, providing the stability and power needed for a variety of agricultural tasks. It is equipped with a hydrostatic power steering system, offering ease of maneuverability. The R3039H features a hydrostatic transmission with infinite (3-range) forward and reverse gears. Powered by a Mitsubishi S4L2 diesel engine, the tractor has a displacement of 107.3 cubic inches and outputs 38.5 horsepower at a rated RPM of 2700. It has an electric starter system and runs on a 12-volt electric system. The liquid-cooled, 4-cylinder engine ensures efficient operation and durability. This model has a wheelbase of 65.4 inches and an operating weight of 2780 lbs. The tractor has multiple tire options, including agricultural, turf, and industrial types to suit different land conditions. The LS R3039H is designed for optimal performance in a variety of environments and can accommodate different attachments for diverse agricultural applications.
Show more...

Key Specifications

Category: Utility

Power Output: 38.5 hp

Transmission: hydrostatic

Drive Type: 4WD

Operating Weight: 2780

Fuel Type: diesel

LS R3039H vs. Similar Tractors

Power Output
Average
Greater than 35% of similar tractors.
Operating Weight
Below Average
Greater than 23% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4L2
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
-
Cylinders
4-cylinder
Displacement (ci)
107.3 ci
Bore (in)
3.071
Stroke (in)
3.622
Rated RPM
2700
Power Output (hp)
38.5 hp

Transmission

Type
hydrostatic
Forward Gears
infinite (3-range)
Reverse Gears
infinite (3-range)
Total Gears
-

Dimensions

Length (in)
117.6
Width (in)
54.3
Height (in)
92.6
Operating Weight (lb)
2780

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag: Front 7-14, Rear 11.2-24. Turf: Front 25x8.5-14, Rear 41x14-20. Industrial: Front 25x8.5-14, Rear 43x16-20
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
electric
Brake Type
-
Hydraulic System Type
-
