LS MT350E

Last Updated: June 2024

Overview

The LS MT350E is a compact utility tractor that is designed to cater to various agricultural and maintenance tasks. It is powered by an LS L3C19-T turbocharged diesel, 3-cylinder, liquid-cooled engine with a displacement of 114.7 cubic inches, capable of delivering 50 horsepower at 2600 RPM and utilizes common rail direct injection for its fuel system. It comes equipped with an 8-speed synchro shuttle transmission, allowing for eight forward and eight reverse gears. The compact tractor features a 4-wheel drive chassis with power steering, making it agile and easy to maneuver in various terrains. Tires come in different types, such as standard agricultural, optional agricultural, lawn/turf, and industrial, to suit different working conditions. The tractor has a weight of 3724 pounds and dimensions measuring 125 inches in length, 68 inches in width, and 100 inches in height with ROPS, providing a stable and sturdy platform for various tasks. The tractor conforms to Tier IV emissions standards, ensuring it stays within environmental compliance limits. Specific details on the hitch type, lift capacity, PTO speed, and hydraulic system were not provided.
Show more...

Key Specifications

Category: Utility

Power Output: 50

Transmission: Synchro shuttle

Drive Type: MFWD 4WD

Operating Weight: 3724

Fuel Type: Diesel

LS MT350E vs. Similar Tractors

Power Output
Average
Greater than 49% of similar tractors.
Operating Weight
Average
Greater than 32% of similar tractors.

Technical Specifications

Engine

Manufacturer
LS
Model
L3C19-T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
114.7
Bore (in)
3.465
Stroke (in)
4.055
Rated RPM
2600
Power Output (hp)
50

Transmission

Type
Synchro shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
125
Width (in)
68
Height (in)
100 (with ROPS)
Operating Weight (lb)
3724

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD 4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag, Turf, Industrial (depending on tire option chosen)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
