LS i3040

Last Updated: June 2024

Overview

The LS i3040 tractor is a versatile compact utility tractor designed for a variety of tasks. Powered by a Mitsubishi S4L2 four-cylinder, liquid-cooled, diesel engine, it boasts a displacement of 107.3 cubic inches and a power output of 38.5 horsepower at 2700 RPM. The tractor comes equipped with a 12-speed synchro shuttle transmission ensuring efficient operations and easy maneuverability. Its 4x4 MFWD 4WD chassis makes it suitable for challenging terrains and conditions. Steering is enhanced by hydrostatic power, which improves handling and response. Standing at 92.6 inches tall with ROPS, the LS i3040 has a length of 117.6 inches and a width of 54.3 inches, with an operating weight of 2780 pounds. Tires come in various configurations depending on the usage, including agricultural, lawn/turf, and industrial options. The tractor features a Category I hitch type, but additional details on hitch specifications are not provided. With features indicating robust capability and comfort in operation, the LS i3040 is designed to meet the requirements of small-scale farming, landscaping, and property maintenance tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 38.5

Transmission: synchro shuttle

Drive Type: 4WD

Operating Weight: 2780

Fuel Type: diesel

LS i3040 vs. Similar Tractors

Power Output
Average
Greater than 35% of similar tractors.
Operating Weight
Below Average
Greater than 23% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4L2
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
indirect injection
Cylinders
4
Displacement (ci)
107.3
Bore (in)
3.071
Stroke (in)
3.622
Rated RPM
2700
Power Output (hp)
38.5

Transmission

Type
synchro shuttle
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
117.6
Width (in)
54.3
Height (in)
92.6
Operating Weight (lb)
2780

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard(ag): Front: 7-16, Rear: 12.4-24 | Lawn/turf: Front: 25x8.5-14, Rear: 41x14x20 | Industrial: Front: 25x8.5-14, Rear: 43x16-20
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS (assumed from Height (ROPS))
Starter Type
electric
Brake Type
-
Hydraulic System Type
-
