Long R9500

Last Updated: June 2024

Overview

The Long R9500 is a row-crop tractor, recognized for its significant operating weight of 8,170 pounds and the option for added ballast, bringing its weight to 13,700 pounds for increased traction and stability. It is powered by a Perkins 6-cylinder, 354 cubic inches, liquid-cooled, diesel engine, with a natural induction system. The engine runs at a rated RPM of 2250 and connects to a 12-speed manual transmission with 12 forward and 4 reverse gears. This tractor features power-assist steering, enhancing maneuverability on various terrains. The Long R9500 has a wheelbase of 94.34 inches, which aids in improved stability and ride comfort, while the front tire size is 9.50-20 and the rear tire size is 16.9-34. The tractor's dimensions include a length of 150.1 inches and a height at the hood of 62.5 inches, allowing it to operate effectively in diverse farming operations. The specific details of the hitch system, hydraulic system, PTO, and brakes remain unspecified, highlighting the need for owners to refer to the original equipment manufacturer's documentation or dealer for comprehensive details.
Show more...

Key Specifications

Category: Row Crop

Transmission: Manual

Operating Weight: 8170

Fuel Type: Diesel

Long R9500 vs. Similar Tractors

Operating Weight
Below Average
Greater than 28% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural
Cylinders
6
Displacement (ci)
354
Bore (in)
3.875
Stroke (in)
5
Rated RPM
2250
Power Output (hp)
-

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
150.1
Width (in)
-
Height (in)
62.5
Operating Weight (lb)
8170

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Power assist
Coolant Capacity (qts)
-
Front Tire Diameter (in)
20
Front Tire Width (in)
9.5
Rear Tire Diameter (in)
34
Rear Tire Width (in)
16.9
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
