Leyland 802

Last Updated: June 2024

Overview

The Leyland 802 is a utility tractor that carries the proud name of its manufacturer Leyland with a robust and straightforward design. It is powered by Leyland's own 4-cylinder, 4/98 TT turbocharged diesel engine that produces 82 horsepower and has a displacement of 230 cubic inches with a bore and stroke of 3.86x4.92 inches and operates at a rated RPM of 2200. This tractor is tailored for a variety of tasks with its synchromesh transmission featuring 9 forward and 3 reverse gears. Its 4x2 2WD chassis configuration, power steering, and 6550 lbs operating weight make it suitable for a range of agricultural duties. The Leyland 802 runs on standard agricultural tires, with front dimension 7.50x16 and rear dimension 14.00x34, supporting its utility-focused usage. This model's simple yet effective hitch system and its status as a reliable workhorse explain its popularity among farmers and its continued use in various farm operations.
Show more...

Key Specifications

Category: Utility

Power Output: 82

Transmission: Synchromesh

Drive Type: 2WD

Operating Weight: 6550

Fuel Type: Diesel

Leyland 802 vs. Similar Tractors

Power Output
Above Average
Greater than 72% of similar tractors.
Operating Weight
Average
Greater than 50% of similar tractors.

Technical Specifications

Engine

Manufacturer
Leyland
Model
4/98 TT
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
230
Bore (in)
3.86
Stroke (in)
4.92
Rated RPM
2200
Power Output (hp)
82

Transmission

Type
Synchromesh
Forward Gears
9
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
6550

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
12 volt
Brake Type
-
Hydraulic System Type
-
