Leyland 235

Last Updated: June 2024

Overview

The Leyland 235 is a utility tractor designed for a variety of tasks on a farm or smallholding. With a simple yet robust 4x2 2WD chassis and manual steering, this tractor is particularly suitable for maneuvering in small spaces. It is equipped with a 28 horsepower Leyland 18T diesel engine which is liquid-cooled, offering enough power to handle day-to-day operations efficiently. It offers a practical range of speeds with its 9 forward and 3 reverse gear transmission system. The dry disc clutch provides reliable transmission engagement, making shifting gears smooth for the operator. The wheelbase of 67 inches and weight of 2710 lbs demonstrate its midrange size and mass, offering good stability and traction with its Ag tires sized 5.50-16 at the front and 14-24 at the rear.

Key Specifications

Category: Utility

Power Output: 28

Transmission: Gear

Drive Type: 2WD

Operating Weight: 2710

Fuel Type: Diesel

Image Gallery

Leyland 235 Tractor

Leyland 235 vs. Similar Tractors

Power Output

Below Average

Greater than 23% of similar tractors.

Operating Weight

Below Average

Greater than 22% of similar tractors.

Technical Specifications

Engine

Manufacturer: Leyland
Model: 18T
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally aspirated (Assumed)
Cylinders: 4
Displacement (ci): 109
Bore (in): 3.16
Stroke (in): 3.5
Rated RPM: 2500
Power Output (hp): 28

Transmission

Type: Gear
Forward Gears: 9
Reverse Gears: 3
Total Gears: -

Dimensions

Length (in): -
Width (in): -
Height (in): -
Operating Weight (lb): 2710

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: Manual
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): 5.5
Rear Tire Diameter (in): -
Rear Tire Width (in): 14
Front/Rear Rim Diameter (in): Unknown (Assumed to be standard for the tire sizes provided but not explicitly listed)
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: Category I
Hitch Category: Category 3 (Assumed based on Rear Type I)
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: -
Brake Type: -
Hydraulic System Type: -
