Landini Globus 80

Last Updated: June 2024

Overview

The Landini Globus 80 is a utility tractor well-suited for a variety of agricultural tasks. Powered by a Perkins 1004-42, four-cylinder diesel engine with a liquid-cooled system, it delivers a respectable 80 horsepower. It operates at an engine-rated RPM of 2200. The Globus 80’s chassis configuration is a 4x2 2WD, and it is equipped with hydrostatic power steering, enhancing maneuverability and ease of operation. It has several transmission options, including a synchronized shuttle and partial power shift, featuring up to 60 forward and reverse gears. The tractor can accommodate agricultural, lawn/turf, and industrial tire setups, indicating its versatility on different terrains. The existence of a 4WD option suggests variants within the model range, but specific details about the 4WD chassis and cab dimensions are provided without clear delineation for the standard model. The Landini Globus 80 has a rear Category 3 hitch, and it is capable of using a range of attachments to suit various agricultural tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 80

Transmission: Synchronized shuttle, Partial power shift

Drive Type: 2WD

Operating Weight: 6820 (max for 4WD model)

Fuel Type: diesel

Landini Globus 80 vs. Similar Tractors

Power Output
Above Average
Greater than 71% of similar tractors.
Operating Weight
Above Average
Greater than 79% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
1004-42
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
-
Cylinders
4
Displacement (ci)
258
Bore (in)
4.055
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
80

Transmission

Type
Synchronized shuttle, Partial power shift
Forward Gears
-
Reverse Gears
-
Total Gears
60

Dimensions

Length (in)
Unknown (4WD Length: 158, GT Length: 157)
Width (in)
Unknown (4WD Width: 78, GT Width: 72)
Height (in)
Unknown (4WD Height (cab): 95.5, GT Height (cab): 91)
Operating Weight (lb)
6820 (max for 4WD model)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
30 (for 14.9R30 tire)
Rear Tire Width (in)
14.9 (for 14.9R30 tire)
Front/Rear Rim Diameter (in)
-
Tire Type
ag, lawn/turf, industrial
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Unknown (GT and 4WD variants have a cab)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
