Landini Advantage 60F

Last Updated: June 2024

Overview

The Landini Advantage 60F is an orchard and vineyard tractor designed for narrow row applications. It features a mechanical shuttle transmission, offering 12 forward and reverse gears. This tractor is powered by a turbocharged aftercooled diesel engine from Perkins, specifically the 3.152 model with a liquid-cooling system. It has 3 cylinders and a displacement of 152.7 cubic inches, with an engine-rated RPM of 2250. With regard to its physical dimensions, it has a length of 131.1 inches and a width of 52.4 inches, accommodating various agricultural tasks. The height differs depending on the presence of a steering wheel or cab, measuring 57.1 inches at the steering wheel and reaching 88.6 inches with the cab. The operating weight ranges from 4872 to 5247 pounds, outlining its sturdy build suitable for various field operations. Designed to operate in different situations, the tractor is equipped with power steering, enhancing maneuverability in tight spaces common in orchard and vineyard environments.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 60

Transmission: Mechanical shuttle

Drive Type: 2WD

Operating Weight: 4872 (2WD ROPS), 5247 (4WD ROPS)

Fuel Type: Turbocharged aftercooled diesel

Landini Advantage 60F vs. Similar Tractors

Power Output
Average
Greater than 33% of similar tractors.
Operating Weight
Average
Greater than 68% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
3.152
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Turbocharged aftercooled diesel
Induction Type
Turbocharged aftercooled
Cylinders
3
Displacement (ci)
152.7
Bore (in)
3.6
Stroke (in)
5
Rated RPM
2250
Power Output (hp)
60

Transmission

Type
Mechanical shuttle
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
131.1
Width (in)
52.4
Height (in)
57.1 (steering wheel), 88.6 (cab)
Operating Weight (lb)
4872 (2WD ROPS), 5247 (4WD ROPS)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS (2WD, 4WD), Cab (Unknown if available)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
