Landini Advantage 55F

Last Updated: June 2024

Overview

The Landini Advantage 55F is an orchard/vineyard tractor suitable for specialized farming tasks. Equipped with a robust engine from Perkins, known as the 3.152, it offers 53 horsepower, liquid cooling, and a displacement of 152.6 cubic inches. The 3-cylinder diesel engine, complemented by its mechanical shuttle transmission, offers 12 forward and reverse gears, customizable with a creeper option for an expanded range of 24 forward and 12 reverse gears. With its power steering and a 2WD chassis configuration, the tractor ensures maneuverability within the close confines of orchard rows. Designed for comfort and efficiency, it presents a height of 87.4 inches with the cabin option and an operating weight ranging from 4806 to 5137 pounds, differing with the choice of ROPS or cab configurations. The overall dimensions, including a length of 131.1 inches and width of 52.4 inches, support its use in narrow land settings. The front and rear tire options, including size 7.50-15 for 2WD and 13.6-24, indicate a balance of stability and soil protection. The electric starter system, along with an undefined hydraulic and PTO system, speaks to the convenience and utility expected of modern tractors in this category. The narrative serves to provide objective, vital information regarding the capabilities and specifications of the Landini Advantage 55F to owners or service personnel.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 53

Transmission: Mechanical shuttle

Drive Type: 2WD

Operating Weight: 4806 to 5137 (depending on configuration)

Fuel Type: Diesel

Landini Advantage 55F vs. Similar Tractors

Power Output
Below Average
Greater than 22% of similar tractors.
Operating Weight
Above Average
Greater than 79% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
3.152
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
152.6
Bore (in)
3.6
Stroke (in)
5
Rated RPM
2250
Power Output (hp)
53

Transmission

Type
Mechanical shuttle
Forward Gears
12
Reverse Gears
12
Total Gears
12 forward, 12 reverse (24 forward, 12 reverse with creeper)

Dimensions

Length (in)
131.1
Width (in)
52.4
Height (in)
87.4 (height with cab)
Operating Weight (lb)
4806 to 5137 (depending on configuration)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
Unknown (front tire size mentioned: 7.50-15 for 2WD)
Front Tire Width (in)
Unknown (cannot be established from 7.50-15)
Rear Tire Diameter (in)
Unknown (rear tire size mentioned: 13.6-24 for 2WD)
Rear Tire Width (in)
Unknown (cannot be established from 13.6-24)
Front/Rear Rim Diameter (in)
-
Tire Type
AG (Agricultural)
Manufacture - End Year
-
Hitch Type
Unknown (Rear Type II is mentioned but does not fit the specific field)
Hitch Category
Unknown (Rear Type II is mentioned but no category defined as "Category 3")
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Unknown (ROPS weight is mentioned but not the type of operator station)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
