Landini 8560F

Last Updated: June 2024

Overview

The Landini 8560F is an Orchard/Vineyard tractor, designed to operate efficiently in specialized farming environments. It features a 4x2 2WD chassis that supports precise maneuvering among tight rows. Power steering ensures responsive handling for the operator. The tractor is equipped with a syncromesh transmission offering a total of 24 forward and 12 reverse gears. This includes options for creeper speeds which are essential for tasks that require slow, controlled movement. Its heart is a Perkins 4.248 diesel engine with 4 cylinders and a liquid cooling system. The engine is rated at 80 horsepower and 59.7 kW of power, with a displacement of 248 cubic inches. It has a bore and stroke measurement of 3.975x5.00 inches, respectively. An electric starter with a 12-volt system gets the tractor running. The Landini 8560F is a practical choice for specialized agricultural tasks where reliability and performance in confined spaces are crucial.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 80

Transmission: Syncromesh

Drive Type: 2WD

Fuel Type: Diesel

Landini 8560F vs. Similar Tractors

Power Output
Average
Greater than 56% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
4.248
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural (assumed due to lack of forced induction data)
Cylinders
4
Displacement (ci)
248
Bore (in)
3.975
Stroke (in)
5
Rated RPM
-
Power Output (hp)
80

Transmission

Type
Syncromesh
Forward Gears
24
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category 2
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
