Kubota MZ655

Last Updated: June 2024

Overview

The Kubota MZ655 is a potent utility tractor designed to perform a range of tasks in various conditions, attractive primarily to users within the agricultural sector. Manufactured between 2010 and 2014, this model boasts a four-wheel drive chassis (4x4 MFWD 4WD) for enhanced traction and improved performance on diverse terrains, complemented by power steering for better maneuverability. At the heart of the MZ655 is the Kubota V3600IDI-T engine, which is a liquid-cooled, turbocharged diesel power unit with four cylinders and 220.9 cubic inches of displacement. The tractor delivers a rated output of 64.1 horsepower at a maximum RPM of 2400, meeting the power requirements for various medium-duty tasks. Additionally, the tractor features a generous wheelbase of 84.7 inches, ensuring stability, and it is equipped with standard agricultural tires, with fronts at 9.5-22 and rears at 12.4-36. This provides ample ground clearance and a versatile tread range conducive to a variety of farm activities. The model offers an array of 24 forward and reverse gears through an electro-hydraulic wet disc clutch, suggesting abilities for precise control over a wide array of operations. With an operating weight of 5622 pounds and a cab height of 98.2 inches, the Kubota MZ655 characteristically supports essential farm endeavors without significant compromise.
Show more...

Key Specifications

Category: Utility

Power Output: 64.1

Drive Type: 4WD

Operating Weight: 5622

Fuel Type: Diesel

Kubota MZ655 vs. Similar Tractors

Power Output
Average
Greater than 60% of similar tractors.
Operating Weight
Average
Greater than 46% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V3600IDI-T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
220.9
Bore (in)
3.86
Stroke (in)
4.72
Rated RPM
2400
Power Output (hp)
64.1

Transmission

Type
-
Forward Gears
24
Reverse Gears
24
Total Gears
48

Dimensions

Length (in)
142.7
Width (in)
64.6
Height (in)
98.2
Operating Weight (lb)
5622

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
2014
Hitch Type
Three-Point Hitch
Hitch Category
II/I
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
