Kubota MZ605

Last Updated: June 2024

Overview

The Kubota MZ605 is a utility tractor that was manufactured by Kubota from 2010 to 2014. It features a 59.2 horsepower Kubota V3600IDI engine with indirect injection and liquid cooling, desirable for a range of tasks where power and stamina are required. The tractor boasts a robust chassis with a 4x4 MFWD 4WD drive system, providing superior traction and off-road capability. Power steering facilitates easy handling and maneuverability. With an electro-hydraulic wet disc clutch, the transmission provides 24 forward and reverse speeds. The tractor's dimensions and weight, with a wheelbase of 80.7 inches, length of 142.7 inches, width of 61.6 inches, height (with cab) of 96.3 inches, and an operating weight of 5313 lbs, make it a substantial and sturdy machine suitable for a wide range of agricultural tasks. The machine's standard tires are sized at Front: 8.3-20 and Rear: 12.4-32. The tractor is finished with an electric starter, and while production ceased in 2014, the Kubota MZ605 remains a reliable choice for farmers and agricultural professionals seeking a powerful and efficient tractor for their operations.
Show more...

Key Specifications

Category: Utility

Power Output: 59.2

Drive Type: 4WD

Operating Weight: 5313

Fuel Type: Diesel

Kubota MZ605 vs. Similar Tractors

Power Output
Average
Greater than 56% of similar tractors.
Operating Weight
Average
Greater than 45% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V3600IDI
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
IDI (Indirect Injection)
Cylinders
4
Displacement (ci)
220.9
Bore (in)
3.86
Stroke (in)
4.72
Rated RPM
2400
Power Output (hp)
59.2

Transmission

Type
-
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
142.7
Width (in)
61.6
Height (in)
96.3
Operating Weight (lb)
5313

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2014
Hitch Type
II/I
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
