Kubota MZ50

Last Updated: June 2024

Overview

The Kubota MZ50 is a utility tractor that served in the agricultural industry from 2006 to 2009. Boasting a liquid-cooled Kubota V3300 diesel engine, it generates 49.3 horsepower with a displacement of 202 cubic inches. The engine supports a 24-speed transmission system enabling ample variance in speed for various tasks and situations requiring precise control. The MZ50 comes with a four-wheel drive (4WD) on a 4x4 MFWD 4WD chassis, backed by power steering, an electro-hydraulic wet disc clutch, and a 48 total gear system, enabling effective power and maneuverability in diverse terrain. This tractor's utility is further amplified by its substantial operating weight of 5225 pounds, ensuring stability and heavy-duty capacity. The cab design provides protection and comfort for the operator while handling agricultural tasks. With a wheelbase of 80.7 inches and a ground clearance of 15 inches, the MZ50 is flexible enough to manage a variety of environments with ease.
Show more...

Key Specifications

Category: Utility

Power Output: 49.3

Drive Type: 4WD

Operating Weight: 5225

Fuel Type: Diesel

Kubota MZ50 vs. Similar Tractors

Power Output
Average
Greater than 47% of similar tractors.
Operating Weight
Average
Greater than 44% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V3300
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
202
Bore (in)
3.86
Stroke (in)
4.33
Rated RPM
2400
Power Output (hp)
49.3

Transmission

Type
-
Forward Gears
24
Reverse Gears
24
Total Gears
48

Dimensions

Length (in)
142.7
Width (in)
61.6
Height (in)
95.1 (cab)
Operating Weight (lb)
5225

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
15 // Unknown
Tire Type
Ag
Manufacture - End Year
2009
Hitch Type
-
Hitch Category
II/I
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
