Kubota MD87

Last Updated: June 2024

Overview

The Kubota MD87 is a utility tractor that was manufactured by Kubota between the years of 1995 and 2001. It features a 4x4 MFWD 4WD chassis, a Kubota V4702 four-cylinder diesel engine, and a liquid-cooled system with a displacement of 284.7 cubic inches. The engine is capable of delivering 85.8 horsepower at 2400 RPM and a torque of 235.1 lb-ft at 1200 RPM. The MD87 is equipped with a partial power shift transmission which includes a creeper gear, allowing it to handle a variety of tasks with its 24 forward and reverse gears. The tractor operates on standard agricultural tires, with front dimensions of 9.5-24 and rear dimensions of 13.9-36. With an overall length of 152.8 inches, a width of 74 inches, and a height of 102.8 inches, and a wheelbase of 90.6 inches, the MD87 has an operating weight of 6812 pounds with a Rollover Protective Structure (ROPS) and 7209 pounds with a cab. The tractor also has a Category II hitch and a ground clearance of 17.3 inches, making it well-suited for a variety of utility roles on the farm.
Show more...

Key Specifications

Category: Utility

Power Output: 85.8

Transmission: Partial power shift, Creeper

Drive Type: 4WD

Operating Weight: 6812 (ROPS) / 7209 (Cab)

Fuel Type: Diesel

Kubota MD87 vs. Similar Tractors

Power Output
Above Average
Greater than 74% of similar tractors.
Operating Weight
Excellent
Greater than 90% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V4702
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
284.7
Bore (in)
4.29
Stroke (in)
4.92
Rated RPM
2400
Power Output (hp)
85.8

Transmission

Type
Partial power shift, Creeper
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
152.8
Width (in)
74
Height (in)
102.8
Operating Weight (lb)
6812 (ROPS) / 7209 (Cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
15.3
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
2001
Hitch Type
Category II
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
